Rivet nut SPYDER XS
Rivet nut, galvanised, steel, M-dome / flat, soft materials
RIVETNUT SPYDER XS M6
Register now and access more than 125,000 products
Rivet nut Spyder XS is excellent for riveting soft materials.
Galvanised steel.
Will not damage soft materials, such as plastics. Can also be used on uneven surfaces.
Datasheets(X)
 | |
Material | Steel |
Surface | Zinc plated |
Thread type x nominal diameter (D) | M6 |
Head diameter (d1) | 16 mm |
Outer diameter (d2) | 12 mm |
Length (l1) | 18.6 mm |
Head height (k1) | 1.6 mm |
Min./max. grip range (s1) | 0.38-4.75 mm |
Design | Open |
Head type | Truss head |
