Blind rivet ST/ST countersunk head open
Blind rivet steel zinc ptd./steel zinc ptd. cs hd
BLIND RIVET ST/ST CSUNK 3,2X8
Register now and access more than 125,000 products
Rivet: St
Feed shaft: St
Datasheets(X)
 | |
Nominal diameter (d1) | 3.2 mm |
Length (l1) | 8 mm |
Head diameter (dk) | 6.0 mm |
Head height (k1) | 0.9 mm |
Material of sleeve | Steel |
Material of mandrel | Steel |
Surface of the sleeve | Zinc plated |
Surface of the mandrel | Zinc plated |
Min./max. grip range | 3.0-5.0 mm |
Shear-fracture load | 1160 N |
Tensile fracture load | 1380 N |
Nominal diameter x length (Ø d x l) | 3.2 x 8 mm |
Head type | Countersunk head 120 degree |
Head angle | 120 Degree |
